Dawnice Battery
20kWh Battery Home Energy Storage
Model HZEB-LCT-20 | 51.2V 400Ah Wall-Mounted Lithium Battery
HZEB-LCT-20 20kWh Specifications
- Product Name: Dawnice 20 kw battery
- Brand: Dawnice
- Model Number: HZEB-LCT-20
- Features: Highly Efficient, Compact Design, Large Capacity, Smart control
- Communication Port: RS485, RS232
- Capacity: 410Ah
- Rated Energy(kWh): 21kWh
- Certification(Battery): UN38.3, MSDS, IEC62619(CB), CE-EMC
- Cycle Time: Core component life >15 years 12000 cycle life
Product Overview
HZEB-LCT-20 kw Solar Battery Features
- High Efficiency: 95% charge/discharge efficiency for optimal energy use.
- Compact & Lightweight: 11% smaller volume, 53.3% less footprint, and 19.1% lighter.
- Large Capacity & Cost-Effective: Single high-capacity battery offers better value compared to 10kWh and low-voltage stack systems.
- Smart Control: Supports Bluetooth and WiFi for cloud-based remote management.
- Upgraded Performance: Higher power output, improved charge/discharge currents, and enhanced materials throughout.
Dawnice HZEB-LCT-20 Technical Specifications
| Model | HZEB-LCT-20 |
|---|---|
| Nominal Voltage | 51.2V |
| Sell model/Configuration | 3.2V 205Ah /16S2P |
| Capacity(Ah) | 410Ah |
| Rated Energy(kWh) | 20.992kWh |
| Max Charge/Discharge Current(A) | 150A/150A |
| Voltage Range(Vdc) | 44.8-57.6V |
| Scalability | Up to 6 parallel |
| Communication | RS232-PC/Solarbank-RS485(B)/Inverter Carbus-Inverter |
| Cycle Life | ≥8000cycles@25℃, 80%DOD |
| Warranty Life | 10 Years (Cycle Life 15Years(25℃)) |
| Weight(Net/Gross)(KG) | 180kg |
|---|---|
| Dimension(W/D/H)(mm) | 265*650*973mm |
| Installation Mode | On the ground |
| IP Grade | IP21 |
| Safety(Pack) | UN38.3/MSDS/EC026/19(CB)/CE-EMC |
|---|---|
| Safety(Cell) | UN38.3/MSDS/EC26/19.CE/UL1973/UL9540 |
| Protection | BMS,Breaker |
| Operating Temperature(℃) | Charge 0℃-50℃; Discharge -10℃-50℃ |
|---|---|
| Altitude(km) | ≤2000m |
| Humidity | <95% (Non-condensing) |
